| PMDC MOTOR Technical Data | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| PMDC MOTOR Model | Rated Voltage (V) | No-Load | Rated | Stall | |||||||
| Operating Range | Nominal | Speed | Current | Speed | Current | Torque | Power | Current | Torque | ||
| RPM | mA | RPM | mA | mN.m / gf.cm | W | mA | mN.m / gf.cm | ||||
| FK-280SA | 4525 | 1.0~2.0 | 1.2VDC | 8670 | 730 | 6560 | 2240 | 1.74/17.7 | 1.3 | 8430 | 9.61/98 |
| 16245 | 6.0~12.0 | 12VDC | 7300 | 60 | 6027 | 290 | 3.4/34.6 | 2.15 | 1350 | 19.5/198 | |
Click on the tilt font to know more parameters!
We are a factory specialized in producing motors for more than 14 years, and we have three factories. Our professional R&D team, mature management, and experienced engineering sales team will bring you a pleasant purchasing experience.
In order to confirm quality, every step of the process is carefully checked from receiving materials to shipment. Quality is the basis of our development.
We are a factory. We specialize in micro DC motors and DC gear motors for more than 14 years.
We can draw up an Online Assurance Order for our new customers, which can be paid online with Master Card, Visa, etc. Customers can also pay with PayPal, TT, etc.
Yes, we can customize a suitable motor according to our customer's specific requirements.
Yes, we have CE, FCC, ISO, etc. If you have other certificate requirements, we can apply for them for you.
We have professional inspection staff on every production line process. After finishing the motor assembly, we use dedicated testing machinery, such as Hardness Testers, 2.5D Image Testers, Salt Spray Chambers, Life Testers, Temperature Test Machines, and Noise Testers to verify product quality.
Standard samples will be produced within 2 weeks, while customized samples will be completed within 3 weeks.
