Product Details
Reference Drawing
------ RS - 755 H
------ RS - 775 H
| PMDC MOTOR Technical Data | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Rated Voltage (V) | No-Load | Rated | Stall | |||||||
| Operating Range | Nominal | Speed (RPM) | Current (A) | Speed (RPM) | Current (A) | Torque (mN.m / gf.cm) | Power (W) | Current (A) | Torque (mN.m / gf.cm) | ||
| RS-770H | 8523R | 6.0~12.0 | 12 VDC | 15000 | 2.2 | 13177 | 15.91 | 81/826.2 | 111.8 | 115 | 666.9/6802 |
| RS-775H | 25110R | 6.0~24.0 | 24 VDC | 3478 | 0.15 | 2925 | 0.75 | 44.4/452.9 | 13.35 | 4.07 | 245.7/2506 |
1. Factory Strength
We are a factory specialize in producing motors more than 14 years, professional R&D team mature management will bring you a pleasant shopping experience.
2. Quality Control
In order to confirm quality, from we receive material to shipment to be carefully checked every step of the way. Quality is our basis of our development.
Looking forward to your feedback!
We are a factory. We specialize in micro DC motors and DC gear motors for more than 14 years.
We can draw up an Alibaba Trade Assurance Order online for our new customers, which can be paid online with MasterCard, Visa, etc. Customers can also pay via PayPal, T/T, etc.
Yes, we can customize a suitable motor according to our customers' specific requirements.
Yes, we have CE, FCC, ISO, and other certifications. If you have additional certification requirements, we can apply for them on your behalf.
We have professional inspection staff stationed at every stage of the production line. Once the motor assembly is complete, we use comprehensive testing equipment, including Hardness Testers, 2.5D Image Testers, Salt Spray Chambers, Life Testers, Temperature Testing Machines, and Noise Testers to ensure performance.
Yes, the length of the shaft can be fully customized according to your application requirements.
