Mini electric hobby motor 3V-12V 25000 RPM powerful magnetic propeller with shaft for toy
| PMDC MOTOR Technical Data | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Rated Voltage(V) | No-Load | Rated | Stall | |||||||
| Operating Range | Nominal | Speed | Current | Speed | Current | Torque | Power | Current | Torque | ||
| RPM | mA | RPM | mA | mN.m / gf.cm | W | mA | mN.m / gf.cm | ||||
| FF-130PA | 16155 | 2.0~3.0 | 2.3VDC | 4000 | 70 | 2500 | 300 | 1.32/13.5 | 13.8 | 760 | 3.92/40 |
| 17145 | 3.0~6.0 | 6VDC | 11500 | 100 | 10000 | 390 | 1.27/13 | 1.33 | 2300 | 10/102 | |
| FF-130SH | 2356 | 1.5~3.0 | 3VDC | 12800 | 270 | 10337 | 1130 | 1.9/19.4 | 2.08 | 4750 | 10/102 |
| FK-130PH | 07555 | 6.0~9.0 | 7.19VDC | 2700 | 20 | 1999 | 50 | 0.8/8.16 | 0.17 | 150 | 3/30.6 |
Click on the tilt font to know more parameters!
1. Q: Are you trading company or manufacturer?
A: We're factory. We specialize in micro dc motor and dc gear motor more than 14 years.
2. Q: What is the payment term for new customer?
A: We can draw up an Ali Assurance Order Online for our new customer, which can pay online with Master Card, Visa, etc. Customer also can pay with PayPal or TT etc.
3. Q: I can't find suitable motor on your website, can you customize the motor for me?
A: Yes, we can customize a suitable motor according to our customer's requirements.
4. Q: Do you have certificates for the motors?
A: Yes, we have CE, FCC, ISO, etc. If you have the other certificates requirement, we can apply it for you.
5. Q: How is your Quality Control?
A: We have professional checking staff on every production line process. After finishing the whole motor, we have entire quality machine to test the motor. Such as Hardness Tester, 2.5D Image Tester, Salt Spray Chamber, Life Tester, Temperature Test Machine, and Noise tester etc.
6. Q: What voltage options are available for the 130 series micro DC motors?
A: The 130 series motors support a flexible operating range typically from 1.5V up to 9VDC or higher, depending on the specific model configurations and customization requirements.
Looking forward to your reply!
