Motor Customized Specification is available.
The length of the shaft can be customized.
| Model | Voltage (V) | No-Load | Rated | Stall | ||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Operating Range | Nominal | Speed (RPM) | Current (A) | Speed (RPM) | Current (A) | Torque (mN.m / gf.cm) | Power (W) | Current (A) | Torque (mN.m / gf.cm) | |
| RS-770H (8523R) | 6.0~12.0 | 12 VDC | 15000 | 2.2 | 13177 | 15.91 | 81 / 826.2 | 111.8 | 115 | 666.9 / 6802 |
| RS-775H (25110R) | 6.0~24.0 | 24 VDC | 3478 | 0.15 | 2925 | 0.75 | 44.4 / 452.9 | 13.35 | 4.07 | 245.7 / 2506 |
We are a factory specialized in producing motors for more than 14 years. With three specialized factories, a professional R&D team, mature management, and experienced engineering staff, we ensure a seamless and high-quality production experience.
To ensure the highest standards, every step from incoming materials to final shipment is carefully checked. Quality is the absolute basis of our development.
Gold seller status with high industry credibility.
100% on-time delivery rate ensures your products arrive timely.
Standard samples ready within 2 weeks; custom samples within 3 weeks.
Timely communication with responses guaranteed within 2 hours.
We are a factory. We specialize in micro DC motors and DC gear motors, with over 14 years of manufacturing experience.
We can set up an Online Assurance Order, enabling online payment via Visa, MasterCard, etc. We also accept PayPal, TT, and other payment options.
Yes, we can customize and develop a suitable motor configuration according to your exact requirement specifications.
Yes, we have CE, FCC, ISO, and other essential certificates. If you require specific regional certifications, we can apply for them on your behalf.
We have dedicated QC inspection personnel at every stage of the production line. Fully assembled motors undergo thorough testing using specialized equipment, including Hardness Testers, 2.5D Image Testers, Salt Spray Chambers, Life Testers, Temperature Test Machines, and Noise Testers.
Standard samples are generally completed within 2 weeks, while customized sample configurations are produced within 3 weeks.
